Air Propulsion Motors and Controllers

Our Sparrow series air propulsion systems are not just advanced they're revolutionary. Designed with cutting-edge technology, these motors are compact and lightweight, offering a significant weight reduction in aircraft. This means enhanced thrust efficiency, longer flight ranges, and reduced operational costs.

Explore the Sparrow Series Today – Where Innovation Takes Flight!

APM40

APM40

Maximum Thrust 2.2kg

The APM40 Sparrow Series motor is designed to deliver high thrust efficiency in a compact form factor. Featuring frameless stators and rotors, this motor excels in applications where performance and size constraints are critical.

IP Rating: IP25

Weight: 68 g

Diameter: 44.5mm

Length: 21mm

APM60

APM60

Maximum Thrust 4.2kg

The APM60 Sparrow Series motor is a high-performance, brushless electric motor designed for demanding applications requiring both power and compactness.

IP Rating: IP25

Weight: 159 g

Diameter: 67.2mm

Length: 21mm

APM80

APM80

Maximum Thrust 5.3kg

The APM80 Sparrow Series is a high-performance brushless motor that delivers substantial power in a compact design.

IP Rating: IP25

Weight: 183 g

Diameter: 79mm

Length: 21.5mm

APM95

APM95

Maximum Thrust 4.8kg

The APM95 Sparrow series is a high-performance, waterproof and dust-resistant brushless motor for light- to medium-duty UAVs, ensuring long life and reliability with superior insulation.

IP Rating: IP45

Weight: 175 g

Diameter: 55.6mm

Length: 33.9mm

AMC30

AMC30

Continuous Current: 20A

The ePropelled AMC30 Sparrow Series is a high-performance ESC for lightweight aircraft propulsion. It efficiently converts DC input into 3-phase AC output, ensuring reliable control and optimal performance for electric motors.

IP rating: IP25

Weight: 30 g

Dimensions (L x W x H):
68mm x 29mm x 12mm

AMC40

AMC40

Continuous Current: 40A

The AMC40 Sparrow Series is designed to pair seamlessly with our lightweight propulsion motors, this ESC converts DC input voltage into 3-phase AC output, serving as the vital control unit for the electric motor.

IP Rating: IP25

Weight: 56 g

Dimensions (L x W x H):
78.5mm x 29mm x 17.5mm

AMC45

AMC45

Peak Current (10s): 60A

The AMC45 Sparrow Series is a high-efficiency, lightweight ESC that converts DC to 3-phase AC. It's waterproof, dust-resistant, and built for tough conditions with efficient cooling.

IP Rating: IP54

Weight: 68 g

Dimensions (L x W x H):
73.4mm x 30.8mm x 19.3mm

Propulsion Solutions for Array of Purposes

Elevate your experience with the Falcon Series electric propulsion systems, which feature motors from 1kW to 22kW peak and matching controllers, all engineered with cutting-edge technology. Each Falcon Series product is enhanced by ePConnected™, our advanced software platform that provides seamless updates, intuitive reconfiguration, and real-time data monitoring. With ePConnected™, you can efficiently perform system health checks, adjust custom configurations, and receive instant alerts for potential issues.

Together, the Falcon Series and ePConnected™ deliver unmatched performance and peace of mind, ensuring innovation and excellence soar. Discover the Falcon Series today and experience the pinnacle of technology.

Reach new heights with the Falcon Series and ePConnected™—
Where innovation meets excellence!

APM100

APM100

Peak power up to 2kW at 6,000 RPM

The APM100 Falcon Series motor offers high power and reliability in a compact design. It excels in challenging environments and high-altitude conditions, making it ideal for demanding industrial applications.

IP Rating: IP20

Diameter: 99.2mm

Length: 35.6mm

APM300

APM300

Peak power up to 5kW at 6,000 RPM

The APM300 Falcon Series motor delivers high power and efficiency in a compact, robust design. Its brushless technology ensures reliable performance and effective cooling, even in challenging environments and high altitudes.

IP Rating: IP20

Diameter: 122.2mm

Length: 48.5mm

APM600

APM600

Peak power up to 10kW at 6,000 RPM

The APM600 Falcon Series motor delivers high power in a compact, efficient design. Its frameless brushless technology ensures excellent cooling, reliability, and durability, making it ideal for demanding and high-altitude applications.

IP Rating: IP20

Diameter: 149.2mm

Length: 59.5mm

APM900

APM900

Peak power up to 12kW at 6,000 RPM

The APM900 Falcon Series motor is built for high-power, compact applications, offering exceptional performance and efficiency. Its frameless design ensures superior cooling and durability, making it ideal for high-altitude and demanding conditions with long-term reliability.

IP Rating: IP20

Diameter: 149.2mm

Length: 69.4mm

APM1200

APM1200

Peak power up to 15kW at 6,000 RPM

The APM1200 Falcon Series propulsion motor is a high-power, compact solution featuring frameless stators and rotors. Engineered for exceptional performance and durability, it offers superior efficiency and reliability, even at higher altitudes.

IP Rating: IP20

Diameter: 171.1mm

Length: 64.5mm

iAMC100

iAMC100

Peak power from 1.2kW (at 48 VDC) to 2kW (at 84 VDC)

The iAMC100 Falcon Series controllers optimize lightweight aircraft propulsion with waterproof, precise control, converting DC to 3-phase AC. ePConnected™ for enhanced software control.

IP Rating: IP54

Weight: 150 g

Dimensions (L x W x H):
110mm x 64mm x 47mm

iAMC300

iAMC300

Peak power from 1.2kW (at 48 VDC) to 5kW (at 84 VDC)

The iAMC300 Falcon Series converts DC to 3-phase AC, enhancing aircraft propulsion with real-time adaptation for optimal performance and stability. ePConnected™ - Enhanced with software control.

IP Rating: IP20

Weight: 200 g

Dimensions (L x W x H):
114mm x 89mm x 60mm

iAMC600

iAMC600

Peak power up to 10kW (at 96 VDC)

The iAMC600 Falcon Series is an advanced controller for UAV air motors, optimizing performance with real-time monitoring and adaptive control for precise operation in varying conditions. ePConnected™ - Enhanced with software control.

IP Rating: IP20

Weight: 565 g

Dimensions (L x W x H):
131mm x 157mm x 39mm

iAMC1200

iAMC1200

Peak power up to 15kW (at 84 VDC)

The iAMC1200 Falcon Series controllers convert DC to 3-phase AC, offering high efficiency and real-time adaptation for optimal stability and precision in aircraft propulsion. ePConnected™ - Enhanced with software control.

IP Rating: IP20

Weight: 1,950 g

Dimensions (L x W x H):
180mm x 190mm x 91.5mm

Hybrid-Ready Power Systems

Optimize your Hybrid Vehicles with our advanced starter generators and iPS/PMU systems ranging from 750W to 12kW. Our compact Electronic Engine Starter, paired with the EESMC6000 motor controller, delivers up to 10kW peak power. Our electronic engine starters, ranging from 3kW to 6kW, also offer significant weight savings. Experience superior performance and efficiency with our high-temperature, lightweight solutions.

Enhance your aircraft’s performance with our lightweight, high-power solutions!

SG750

SG750

Output power of 750W

The ePropelled SG750 Hercules Series delivers high performance and reliability for UAVs, providing extended flight times and quiet operation in a compact, efficient design.

Diameter: 101mm

Length: 29.2mm

No-Load, Line-to-Line
Voltage Constant: 7.4 Vac/1000 RPM

SG1500

SG1500

Output power of 1.6kW

The ePropelled SG1500 Hercules series delivers high performance, extended flight times, and reduced noise in a compact, robust design for UAVs.

Diameter: 127mm

Length: 41.9mm

No-Load, Line-to-Line
Voltage Constant: 6.6 Vac/1000 RPM

SG3000

SG3000

Output power of 3kW

The ePropelled SG3000 Hercules Series provides exceptional performance for UAVs with extended flight times, low noise, and high power. Its advanced design makes it a leading choice in UAV propulsion.

Diameter: 127mm

Length: 41.9mm

No-Load, Line-to-Line
Voltage Constant: 6.6 Vac/1000 RPM

SG6000

SG6000

Output power of 8kW

The ePropelled SG6000 Hercules Series Starter Generator delivers high performance and versatility for UAVs with its slimline design and advanced technology.

Diameter: 186mm

Length: 50.9mm

No-Load, Line-to-Line
Voltage Constant: 7.5 Vac/1000 RPM

SG12000

SG12000

Output power of 13kW

The ePropelled SG12000 Hercules Series Starter Generator offers exceptional power, extended flight time, and reduced noise, designed to meet the high demands of UAV applications.

Diameter: 190mm

Length: 68mm

No-Load, Line-to-Line
Voltage Constant: 9.5 Vac/1000 RPM

EESMC6000

EESMC6000

Output power of 10kW

The EESMC6000 can operate in propulsion mode and converts the starter generator into a propulsion motor (SGPM6000) which assists the ICE and provides the UAV with additional takeoff, landing, and agile maneuvering power.

IP Rating: IP20

Weight: 1900 g

Dimensions (L x W x H):
216.5mm x 190mm x 61.78mm

EES3000

EES3000

Output power of 3kW

The electronic engine starter EES3000 Hercules Series powers the starter generator during the engine start sequence and can be triggered digitally via the controller area network (CAN) interface, or physically through pins on the connector.

IP Rating: IP20

Weight: 950 g

Dimensions (L x W x H):
178.5mm x 152.4mm x 45mm

EES6000

EES6000

Output power of 10kW

The electronic engine starter EES6000 Hercules Series powers the starter generator during the engine start sequence and can be triggered digitally via the controller area network (CAN) interface, or physically through pins on the connector.

IP Rating: IP20

Weight: 995 g

Dimensions (L x W x H):
216.5mm x 190mm x 51.13mm

iPS750

iPS750

Output power of 750W with 28V/48V

The iPS750 Hercules Series converts 3-phase AC to regulated DC power for aviation systems and includes an electronic engine starter (EES) that switches to regulated voltage once the engine reaches operational speed.

IP Rating: IP20

Weight: 780 g

Dimensions (L x W x H):
201.9mm x 99.3mm x 54.0mm

iPS1500

iPS1500

Output power of 1.5kW with 28V/48V

The iPS1500 Hercules Series converts 3-phase AC to regulated DC power for avionics and other aviation systems, featuring an electronic engine starter (EES) that switches to regulated voltage at operational speed.

IP Rating: IP20

Weight: 1,115 g

Dimensions (L x W x H):
204.8mm x 155.2mm x 50.0mm

iPS3000

iPS3000

Output power of 3kW with 28V/48V

The iPS3000 Hercules Series is a cutting-edge power management solution for UAVs, converting 3-phase AC to regulated DC power, boosting efficiency, and reducing size and costs.

IP Rating: IP20

Weight: 1,540 g

Dimensions (L x W x H):
286.4mm x 152.4mm x 52.6mm

iPS6000

iPS6000

Output power of 6kW with 28V/48V

The iPS6000 Hercules Series is a high-performance UAV power system, converting 3-phase AC to regulated DC for enhanced reliability, efficiency, and reduced size and costs.

IP Rating: IP20

Weight: 2,800 g

Dimensions (L x W x H):
295.3mm x 277.6mm x 52.6mm
